ASB116 US Motors 5 Hp 3450 RPM 56Y 208-230V (ODP) High Efficiency Switchless Pool Pump Motor

Original price was: $334.00.Current price is: $95.99.

SKU: ZWXLY 1698655103 Categories: Pool & Spa Motors, US Electric Motors Tag: US Motors

Efficient and effective customer service, online.
Free Shipping, No Compromise on Quality
Get the Best for Less
Online assistance, always just a message away.

Description
Reviews (0)

US Motor Premium Energy Efficient 56J Pool Motor

5 THP (Total Horsepower)
3450 RPM, 21.0-19.4 amps, 208-230V 60hz. Single Phase
NEMA 56J frame (with mounting base)
5/8″ diameter threaded stainless steel shaft
Overload Protection: Auto. Class B insulation, 6.5″ body dia.
Non-Reversible – CCW Rotation facing the shaft
C-Face Mount, Ball Bearings, Open Drip Proof (ODP)
Sealed ball bearings
Wiring diagram on motor name plate
1 year warranty

US Model K063DGN5174023J

ATTENTION CALIFORNIA CUSTOMERS: This pump/motor does not comply with California’s Efficiency Regulations. These regulations can be found in Title 20, in the California Code of Regulations (CCR) sections 1601-1609. To meet California’s requirement, the pump/motor must be a 2 speed. So, it’s illegal to ship this pump/motor to California as it’s in violation of their regulations.
