Original price was: $380.18.$99.99Current price is: $99.99.
- Efficient and effective customer service, online.
- Free Shipping, No Compromise on Quality
- Get the Best for Less
- Online assistance, always just a message away.
- 1/2 hp 1800 RPM, 9.0/4.3-4.5 amps 115/208-230V Volts 60 Hz Capacitor Start Motor
- NEMA 48 Frame, Rolled Steel with Cast Aluminum End Bells, Keyed Shaft 1/2″ Diameter x 1 1/2″
- Service Factor: 1.15 Overload protection = None
- Rigid Mount, Ball Bearings, Class B Insulation, Reversible
- 1 Year Manufacture Warranty
For used on air compressors, pumps, and conveyor requiring high starting torque. Wiring diagram on motor name plate. TEFC = Totally Enclosed Fan Cooled. C055KLD4993015B
Be the first to review “T12C2J4 Nidec 1/2 Hp 1800 RPM 115/208-230V 48 Frame (Rigid Base) 1-Speed TEFC Cap Start Motor”
